Problem 3.3. Suspended bar- additional end weight

An additional mass, M is hanged at the end of the bar given in the previous problem. Determine the strains of the bar at the end and at the midheight.

Solve Problem

SolveHide solve

Determine parametrically the strain at the end.

Check solution

$ε (L) = \frac{G g}{E A}$

Determine parametrically the strain at midheigth.

Check solution

$ε (\frac{L}{2}) = \frac{G g + ρ g A L / 2}{E A}$

Do you need help?

Steps

Step by stepHide steps

Step 1. Give the differential equation and its general solution for a tensile rod.

Check general solutionHide general solution

The differential equation and the general solution is equivalent to that of the previous problem (suspended rod subjected to its self-weight).

See Eq.(3-26)

$- E A \frac{d^{2} u^{}}{d x^{2}} = ρ g A$

$u = u_{hom} + u_{part} = C_{1} + C_{2} x - \frac{ρ g}{E} \frac{x^{2}}{2}$

Step 2. Determine the constants from the boundary conditions.

Check constantsHide constants

At the support the displacement is zero, at the lower end the normal force is equal to the concentrated load.

$at x = 0 u = 0 \to C_{1} = 0 at x = L N = M g N (L) = E A (C_{2} - \frac{ρ g}{E} L) = M g \to C_{2} = \frac{M g + ρ g A L}{E A}$

Step 3. Give the displacement and strain functions. Calculate the values of the strain function at the end and at the midheight.

Check resultHide result

$u = C_{2} x - \frac{ρ g}{E} \frac{x^{2}}{2} = \frac{M g + ρ g A L}{E A} x - \frac{ρ g}{E} \frac{x^{2}}{2} ε = C_{2} - \frac{ρ g}{E} x = \frac{M g + ρ g A L}{E A} - \frac{ρ g}{E} x ε (L) = \frac{M g + ρ g A L}{E A} - \frac{ρ g}{E} L = \frac{M g}{E A} ε (\frac{L}{2}) = C_{2} - \frac{ρ g}{E} x = \frac{M g + ρ g A L / 2}{E A}$

Step 4. Draw the strains and the displacement diagrams.

Check figureHide figure

Results

Worked out solutionHide solution

The differential equation and the general solution is equivalent to that of the previous problem (suspended rod subjected to its self-weight).

See Eq.(3-26)

$- E A \frac{d^{2} u^{}}{d x^{2}} = ρ g A$

$u = u_{hom} + u_{part} = C_{1} + C_{2} x - \frac{ρ g}{E} \frac{x^{2}}{2}$

However, one of the the boundary conditions is different. At the support the displacement is zero, at the lower end the normal force is equal to the concentrated load. The constants are

$at x = 0 u = 0 \to C_{1} = 0 at x = L N = M g N (L) = E A (C_{2} - \frac{ρ g}{E} L) = M g \to C_{2} = \frac{M g + ρ g A L}{E A}$

The displacement and strain functions can be determined:

$u = C_{2} x - \frac{ρ g}{E} \frac{x^{2}}{2} = \frac{M g + ρ g A L}{E A} x - \frac{ρ g}{E} \frac{x^{2}}{2} ε = C_{2} - \frac{ρ g}{E} x = \frac{M g + ρ g A L}{E A} - \frac{ρ g}{E} x$

The values of the strain function at the end and at the midheight are given below.

$ε (L) = \frac{M g + ρ g A L}{E A} - \frac{ρ g}{E} L = \frac{M g}{E A} ε (\frac{L}{2}) = C_{2} - \frac{ρ g}{E} x = \frac{M g + ρ g A L / 2}{E A}$

the value of the strain functio

The strains and the displacement diagrams are given in the Figure.
