Problem 7.3. Displacement magnification factor

Approximate the percentage increase of the moment at the bottom of the column given in the Figure taking into account the second order effect of the normal force. In the approximation use the displacement magnification factor (or moment magnification factor). Bending stiffness of the steel profile is: EI = 1.46×10⁷ kNcm².

Solve Problem

SolveHide solve

Increase of the moment due to second order effect [%]=

Do you need help?

Steps

Step by stepHide steps

Step 1. Calculate the critical load of the column.

Check critical loadHide critical load

Eq.(7-29)

N_{cr} = \frac{π^{2} E I}{l_{0}^{2}} = \frac{π^{2} \times 1.46 \times 10^{7}}{{(2 \times 260)}^{2}} = 532.9 kN

Step 2. Determine the displacement magnification factor.

Check displacement magnification factorHide displacement magnification factor

Eq.(7-35)

ψ = \frac{1}{1 - \frac{N}{N_{c r}}} = \frac{1}{1 - \frac{100}{532.9}} = 1.23

Step 3. Give the percentage increase of the moment.

Check percentage increaseHide percentage increase

See Eq.(7-36)

M = ψ M_{0} = 1.23 M_{0}

The moment is increased due to second order effect by the displacement magnification factor. The percentage increase is 23%.

Results

Worked out solutionHide solution

The critical load of the column is

Eq.(7-29)

N_{cr} = \frac{π^{2} E I}{l_{0}^{2}} = \frac{π^{2} \times 1.46 \times 10^{7}}{{(2 \times 260)}^{2}} = 532.9 kN

The moment is increased due to second order effect by the displacement magnification factor:

Eq.(7-35)

ψ = \frac{1}{1 - \frac{N}{N_{c r}}} = \frac{1}{1 - \frac{100}{532.9}} = 1.23

See Eq.(7-36)

The increased moment is
$M = ψ M_{0} = 1.23 M_{0}$

The percentage increase is 23%.
